Rittal SK FILTER FAN 180M³/H 230V 50/60HZ REPLACES 3324.107
Original price was: $358.60.$326.50Current price is: $326.50.
The Rittal SK 3240.100 Filter Fan is a high-performance ventilation solution designed for electrical enclosures. Operating at 230V AC with a frequency of 50/60Hz, it provides an air throughput of 180 m³/h at 50Hz and 160 m³/h at 60Hz. This unit is equipped with a diagonal, shaded pole motor and features a standard filter mat for efficient dust filtration. With an IP54 protection rating, it ensures reliable operation in various industrial environments. The fan is easy to install with a snap-in mounting system and is suitable for applications requiring compact and effective cooling solutions.
| Weight | 2.5 kg |
|---|
Complete fan unit for tool-free mounting on surfaces. Air throughput from 20 – 900 m³/h, standard protection category IP 54.
Fan-and-filter units with diagonal fan technology have superior pressure stability and ensure a more constant air throughput.The diagonal direction of outflow ensures more even heat dissipation from the enclosure.
SK Fan-and-filter unit TopTherm, 175/155 m³/h, 230 V, 1~, 50/60 Hz, WHD: 255 x 255 x 25 mm
Technical Specifications
- Article number : SK 3240.100
- Colour : RAL 7035
- Supply includes : Complete unit ready to install, including chopped-fibre filter mat
- Fan : Diagonal, shaded pole motor
- Air throughput, unimpeded airflow (with chopped-fibre filter) : At 50 Hz: 175 m³/h , At 60 Hz: 155 m³/h
- Air throughput, unimpeded airflow (with pleated filter) : At 50 Hz: 218 m³/h , At 60 Hz: 188 m³/h
- Air throughput with outlet filter including chopped-fibre filter mat (quantity x order number) : 1 x 3240200: 130/110 m³/h
- Rated operating voltage : 230 V, 1~, 50 Hz/60 Hz
- Power consumption Pel : At 50 Hz: 35 W , At 60 Hz: 34 W
- Rated current max. : At 50 Hz: 0.21 A , At 60 Hz: 0.19 A
- Dimensions : Width: 255 mm, Height: 255 mm
- Mounting cut-out : Cut-out width: 224 mm , Cut-out height: 224 mm
- Installation depth : 107 mm
- IP protection category to IEC 60 529 : IP54 with chopped-fibre filter/pleated filter
- Protection category NEMA : Type 12 with chopped-fibre filter/pleated filter
- Pre-fuse : Miniature circuit-breaker/fuse: 2 A
- Note : To increase the air throughput, a pleated filter may optionally be used (see characteristic curve). Suitable for use with fan-and-filter units, roof-mounted fans and outlet filters.
- Service life of fans (L10, 40 °C) : At 50 Hz: 72,000 h , At 60 Hz: 76,000 h
- Operating temperature range : -30 °C…55 °C
- Storage temperature range : -30 °C…70 °C
- Noise level : At 50 Hz: 51 dB(A) , At 60 Hz: 46 dB(A)
- Packs of : 1 pc(s).
- Weight/pack : 2.26 kg
- Customs tariff number : 84145915
- EAN : 4028177651937
- ETIM 7.0 : EC000320
- ECLASS 8.0 : 27180716
